CORE DREDGE 45
The Prime Dredge 45 is a dredger is a CSD 450 of the highest quality available. This 18 inch dredger is therefore suitable to dredging in large rivers, sheltered area’s on the coastline and can perform activities such as sand mining, river training, harbour deepening, dredging of irrigation channels and much more.
ECT MARINE BV
ENGINEERED PRODUCTS
PRODUCTDATA
CORE DREDGE 45
Production: 3000 m3/hour
Total Installed power: 940 kW
Dredge installation
Dredge pump drive: Caterpillar, Mitsubishi or Cummins
Power:
709kW@1600 rpm
Dredge pump: GIW LSA / Warman
Cutter blades: ECTMarine 5
Tooth system: ESCO Ultralock
Cutter power: 110 kW
Cutter speed: variable 0..30 rpm
Main Dimensions
Length overall, ladder up: 32 m
Length over pontoons: 22 m
Breadth: 7,6 m
Dredging depth: 12 m
Suction pipe diameter: 450 DN
Discharge pipe diameter: 450 DN
Auxiliary drive
(Driving electric generator, winches, cutter, spuds)
Make: Caterpillar, Mitsubishi or Cummins
Power: 232kW@1600rpm
Winches
Ladder winch
Line pull first layer: 80 kN
Speed: 0..20 m/min
Swing winches (2x)
Wire pull first layer: 80 kN
Hauling speed: 0..20 m/min
Electric installation
Voltage: 24V DC and 230V/400V AC
Electric generator: 20 KVA
Tank capacities
Fuel oil (bunker tanks and day tank)
Day tank: 2 m3
Bunker tank: 2X 4,3 m3
Features
High efficiency dredge pump
Transportable by road
Heavy duty design
Low maintenance
Modular design
High quality components
Efficient fuel consumption
Luxurious operator cabin
Class approved construction
Optional equipment
Production measurement
Monohull
Dredge monitoring tracking system
Electric / LNG
Increased dredging depth
Air conditioning
Plain suction front part
Spare parts package
Diesel generator set
Spud carrier system
Single engine set up
Anchorboom installation
