ECT MARINE
CORE DREDGE 25

The Core Dredge 25 is a dredger is a highly mobile and transportable 10 inch Cutter Suction Dredger. The Core Dredge 25 is compact without compromising of performance and capabilities. The dredge can be mobilized and de-mobilized and operated by a single person. The dredger can be supplied with a truck and loading system to make this the most transportable dredge solution on the market. The Core Dredge 25 can be used for sand mining, dam cleaning, deepening of small canals and many more other applications.

ECT MARINE BV
ENGINEERED PRODUCTS
PRODUCTDATA
CORE DREDGE 25

Production: 750 m3/hour

Total Installed power: 175 kW

Dredge installation

Dredge pump drive: Volvo

Power: 175 kW

Dredge pump: 8/6

Cutter: ECTMarine 5 blades

Teeth system: Replaceble teeth

Cutter power: 20 kW

Cutter speed: Variable 0..30 rpm

Main Dimensions

Length overall, ladder up: 14 m

Length over pontoons: 7 m

Breadth: 4 m

Dredging depth: 4 m

Suction pipe diameter: 300 DN

Discharge pipe diameter: 250 DN

Tank capacities

Fuel oil: 1,5 m3

Winches

Ladder winch

Line pull first layer: 15 kN

Speed: 0..20 m/min

Swing winches (2x)

Wire pull first layer: 15 kN

Hauling speed: 0..20 m/min

Optional equipment

Production measurement

Dredge monitoring tracking system

Floating pipeline

Airconditioning

Plain suction dredger

Truck with loading system

Features

High efficiency dredge pump

Transportable by road

High quality components

Efficient fuel consumption

Luxurious operator cabin

Modular design

Heavy duty design
